Instrumentation Technology Lab

List of Equipments in Instrumentation Technology Lab:

Serial Number

Items list

 1  Auto Ranging Digital Picoammeter W. IEEE - 488 Interface Model / Part No - 485/ 4853 S.No - 587189
 2  Temperature Calibrator series TP 18600
 3  Micrologix  1000  PLC
 4 True RMS Autoranging Multimeter Model No - 1087 S.No - 0028026, 030
 5 Head mount temperature transmitter EQ-03 -238
 6 Pressure transmitter EQ -03- 239
 7 7743 - 01 NT PCI - 6024E low cost multifunction I/O 8473, 301080 NLR
 8  776570 - 06 SCXI - 1000, U.K. 240 V ( 4 - slot chassis) 8473.30, 5000NLR
 9 777935 - 01 NI PXI - 7344, 4 axis servo/step motion controller for windows 8473.30.1080 NLR
 10 NI - PXI - 6040 E and NI - DAQ software for win 2000/NT MC/9X 8473.30.1080 NLR
 11 778468 - 01 NI 8176, 1.26 GHz PXI Embedded controller with windows 2000 8471.50.0085 NLR
 12  IMAQ PXI - 1411 and NI - IMAQ 8773.30.1080
 13  Thermo - Anemometer
 14 Professional high temperature laser targeting Infrared Thermometer supplied with 9V battery, DT8839
 15 Multimeter benchtop
 16 Milliampere source portable handhell
 17  Smart Transmitter 0 -30
 18 Pressure Pump with standard guage
 19 Pressure Switch 0 -1
 20 Temp. Switch ( 0 - 100° C)
 21 Solenoid Valve 3 - port 2 - way spool type 1/4"
 22  EQ04 - 710, Digital Temperature Indicator with data logging with 0 - 100° C with RS 232C Interface
 23 EQ04 - 711 , LVDT Trainew Kit ( Model No - TT - LVDT)
 24 Hybrid stepper motor 6 Kg cm
 25  Digital Multimeter 81k - TRMS
 26 Ultrasonic water level sensor 2 - 12"
 27 Solar radiation sensor
 28 4-20 mA Weather station
 29  Tipping bucket rain guage 8""
 30 NI USB 6009 DAQ card
 31  Scientific "Bench top LCR Meter SM 60191103147
 32 Techno - Instruments DC speed controller DCS - 01
 33 Techno - Instruments AC servo motor
 34 Techno -Instruments Synchro sets (Transmitter/Receiver)
 35 Techno - Instruments PID controller PID - 01
 36 Techno - Instrument compensation design
 37 Techno - Instrument temperature controller TCS - 01
 38 Techno - Instrument linear system simulator Disc
 39 Techno- Instrument linear system simulator Disc
 40 DC position control system HEM
 41 Study of potentiometer as error detector HEM
 42 Techno - Instrument DC speed controller
 43 AC servo motor
 44 DC motor position control system
 45 Oscilloscope; Digital storage, 40MHz, 500MSa/s, 2-CH Active
 46 Tristar make RTD (PTD - 100)Head type sensor
 47 Labview FDS Liscence - version 2012
 48 NI WSN starter kit (International)
 49 NI WSN - 32264 channel programmable RTD
 50 NI 9792 Programmable real time controller Integrated WSN Gateway 9 - 35VDC
 51 NI PS -15 Power supply , 24VDC , 5A
 52 NI ELVIS II Hardware ( For Academic use only)
 53 Vernier Bioinstrumentation sensor kit for NI ELVIS II
 54 Vernier Green Engineering sensor kit for NI ELVIS II
 55 NI Academic Site Liscence, Department, Fall 2012 Discount value
 56 GRAS General Purpose Array Microphone
 57 NI USB- 4432- 24 - Bit Sigma Delta ADCs
 58 GRAS General Purpose Array Microphone
 59  USB - 6009 14 - Bit Multifunction I/O and NI- DAQmx
 60 Scientech - strain Guage trainer ST - 2304
 61 Fluke digital multimeter, model - Fluke179
 62 Maxtech - Multi thermometero 0 - 200°C, model - ST - 9269
 63 Scientific LCR - Q - Meter, model - SM6019
 64 LDS Vibrator
 65 Amplifier LDSLPA 100 - 230V
